Description

Year Built / Builder: 2007 / Guangzhou South China SDN BHD. Flag: Malaysia. Class: BV. Accommodation: 14 Men. Main Engines: 2 x ZIBO LB8250ZC-1 (2 x 2000BHP). Propulsion: Manganese Bronze / 4 Blades Solid with key Dia. 2.65 m Fixed Pitch in Kort Nozzle. Max Speed: 12 knots, Service Speed: 10 knots. Bollard Pull: 54.1 T

Specifications

Accommodation

14 Men
1 Man x 4
2 Men x 3
4 Men x 1

Capacities 100%
Fuel Oil: 80.40 m3
Fresh Water: 52.60 m3
Freezer and Cooler: 2.52 m3 / 2.52 m3
Clear Deck Area: 75 m2
Deck Strength: 5 T

Performance
Max Speed: 12 knots
Service Speed: 10 knots
Bollard Pull: 54.1 T

Construction

Depth Moulded: 5.30m
Deadweight: 379.268T
GRT: 495 T
NRT: 148 T

Equipment

Towing / Anchor Handling / Mooring
Towing Drum Wire: 44mm, 500m
Towing Winch: 500 kn HTM
Anchor Windlass: 20.6 kn YMO 8072
Anchors: 2 x Stockless Anchor 660 kg
Anchor Chain: 22 mm Dia. x 27.5m x 6 Length each side
Capstan: 3T
Single Armed Davit: 0.5 T @ 5 m/min, Lutao

Navigation Equipment

Inmarsat C : 2 x Furuno Felcom 15
GMDSS: Comply GMDSS A1+A2+A3
Radars: 1 x Furuno FR-1510 Mark 3, 1 x Furuno 1832
GPS Navigator: 1 x Furuno GP-80, 1 x Furuno GP-32
Autopilot: Unikas CD-50
Navtex Receiver: Furuno NX-700
Magnetic Compass: Daiko SR-150SLK
MF / HF SSB DSC: Furuno FS-2571C
Echo Sounder: Furuno FE-700
VHF Radio Telephone: 2 x Furuno FM-8800S
GMDSS Hand Held Radio: 3 x Entel Ht644
SART: 2 x Safe Sea S100
EPIRB: GME MT403FF
Barometer: Mingle
AIS: Furuno FA-150
Speed Log: Furuno DS-80
BNWAS: Rockson Guardian VII

Engine(s)

Main Engines: 2 x ZIBO LB8250ZC-1 (2 x 2000BHP)
Propulsion: Manganese Bronze / 4 Blades Solid with key Dia. 2.65 m Fixed Pitch in Kort Nozzle
Main Generator: 2 x Cummins NTA855-D(M), 2 x 250 kVA
Harbor Generator: 1 x Cummins 6BTA5.9-D(M), 1 x 78 kW
Boiler: 2 x Oil and Gas Fire Auxiliary Boilers 25 m3, 0.7 bar
Oily Water Separator: Georim Engineering, GRS-05EB, 0.5 m3/hr.
Sewage Treatment Plant: Weihai WCB-20, 1.54 m3/day, 20P
Fuel Oil: 2 x 12 m3/hr @ 5 m head

Safety Equipment

Fire Hydrants: 5 nos.
Fire Extinguishers: 2 x 45 Liters Foam, 4 x 9 Liters Foam, 6 x 9 kg DP, 4 x 9 LW
Safety Equipment: 1 BA Set, 2 x 15 per Life Raft
Fire Detection and Alarm System: Ruian Zhongrui Electron Equipment Co. Ltd.

Disclaimer

The particulars and specifications are supplied by the vendor and not SeaBoats. Such information has not been verified and may be incorrect. Please do not rely on particulars and specifications unless you have verified their accuracy.
